Cup Sealing Machine Automatic vs Semi Automatic Cup Sealing Machine

Automatic cup sealing machines and semi-automatic cup sealing machines are manufactured with the highest quality materials and modern technology. It is easy to operate, and its sealing capacity is 300-400 cups/hour. You can use them to seal coffee, milk, tea, and other beverages. You only need to put the cup in the holder, and the machine will cut the plastic film according to the size of the cup to seal the edge. I will do All this automatically.

cup sealing machine automatic
pouch packaging machine

What is an automatic cup sealing machine

The automatic cup sealing machine is a sealing machine controlled by a computer system. Push the cup holder into the sealing machine before use. After that, it can automatically seal the plastic cup.

What is a semi-automatic cup sealing machine?

A semi-automatic cup sealing machine is a kind of cup sealing machine. It needs to push the cup holder into the machine manually.

Many companies use the automatic cup sealing machine incorrectly. Incorrect use will cause the cup sealing machine to not help the company to better complete the production. It will also shorten the service life of the cup sealing machine. Then let’s talk about the correct use of the cup sealing machine.

First of all, there is almost no significant difference between automatic cup sealing machines and semi-automatic cup sealing machines.

How to use the automatic cup sealing machine?

When in use, the first thing to do is to turn on the power switch. We waited until the indicator light inside the button lights up. Then adjust the speed of the automatic cup sealing machine. Speed adjustment refers to adjusting the speed of the inner conveyor belt of the cup sealing machine. This can better cooperate with production. The next step is to adjust the temperature. We need to change the temperature to a better state. When the temperature reaches a specific value, the temperature indicator of the automatic cup sealing machine will give a hint. Then can carry out the sealing operation.

Through the brief introduction of this article. Do you think that the use of the automatic cup sealing machine is straightforward? That’s right. The above are the simple steps to use the automatic cup sealing machine. Because the device’s design is very advanced and reasonable, every step of the automatic cup sealing machine will have specific prompts. We only need to follow the prompts when using it. In this way, the operation of the automatic cup sealing machine will become simpler and faster.

In addition, reasonable use of the automatic cup sealing machine can effectively guarantee the service life of the device itself. Therefore, no matter what kind of mechanical equipment, we must have the correct use method so that it will be safer to use, and at the same time, it can guarantee the service life of the equipment.

How to use the semi-automatic cup sealing machine?

1.Connect the semi-automatic cup sealing machine to the power supply. First, turn on the power switch, the indicator light of the semi-automatic cup sealing machine is on. The lower mold slide plate automatically slides out of the semi-automatic cup sealing machine. We set the thermostat to a predetermined temperature, and the green heating indicator light is on. When the hot upper plate reaches the predetermined temperature, the red constant temperature indicator light will be. We should pay attention: when the sealing machine is working, the electric heating device is constantly alternated in the heating and heat preservation state. The green and red indicator lights of the semi-automatic cup sealing machine are also displayed alternately.

2.Put the plastic cup into the lower mold slide and press the automatic control switch. We need to manually push the plastic cup into the semi-automatic cup sealing machine. Moving a distance will touch the button. The upper mold of the semi-automatic cup sealing machine automatically presses down and fills after receiving the signal. Touching the switch will delay pressing down for one second. After completion, the automatic cup sealing machine will automatically rise and reset. If you need to repeat this process later, control it on the computer. The semi-automatic cup sealing machine can automatically complete production without manual control. If you want to repeat the operation, we only need to place the items on the semi-automatic cup sealing machine manually.

cup sealing machine automatic
nespresso capsule filling process
cup sealing machine automatic

Maintenance of common problems of cup sealing machine:

The automatic cup sealing machine comprises a frame, a conveying device, and an electronic control system. Its working principle is when the package containing the items is placed on the conveyor belt. The sealing part of the packaging bag is automatically fed between the two sealing belts in operation. And bring it into the heating zone of the automatic cup sealing machine.

The heat of the heating block is transferred to the sealing part of the bag through the sealing belt so that the film is melted and softened by heat. The packaging bag then passes through the cooling zone of the automatic cup sealing machine to make the film surface temperature drop appropriately. Then it rolls by the printing wheel to bond the upper and lower plastic films of the sealing part. And press the printed logo on the automatic cup sealing machine. Then the sealed packaging bag is sent out of the device by the guiding rubber belt and the conveyor belt to complete the sealing operation.

In recent years, with the rapid development of food, medicine, and other industries, automatic sealing machines have also ushered in a broad market. The scale of the industry market continues to expand. And in the fierce competition, automatic sealing machine manufacturers continue to innovate and upgrade their products. They seek to create equipment with a more beautiful appearance, high work efficiency, simple operation, and convenient maintenance. Bring economic benefits to customer development. However, in using the device, users still cannot avoid some common faults that need to be dealt with.

1.Improper sealing

Insufficient sealing is one of the common failures of automatic sealing machines. There are three main reasons for the failure.

The first reason is that it cannot see the seal of the packaging bag. It causes by factors such as low heat sealing temperature and too fast heat sealing speed. If the corona treatment is uneven, the effect is not good, and it cannot close the packaging bags and plastic cups. This situation is rare, but once it occurs, the product must be scrapped. Therefore, after discovering the quality problem, it is necessary to analyze the cause and solve it quickly. Suppose moisture and dirt in the seal will also cause the seal to be insecure. For this failure situation, the solution mainly includes: appropriately increasing the heat sealing temperature, then reducing the heat sealing speed, and increasing the pressure of the cold-pressed rubber wheel at the same time.

The second reason is that although the mouth of the packaging bag or plastic cup is sealed, a little harder squeezing or tearing, the sealing will crack again. This situation is related to low heat-sealing temperature and insufficient flatness of the knife surface of the heat-sealing knife. If the temperature of the automatic cup sealing machine is not enough, it can solve the problem by appropriately increasing the heat sealing temperature. If the hot air knife surface of the automatic cup sealing machine is not neat enough, make corresponding adjustments on the computer

The third reason is that half of the seal is firm when the peeling test is performed on the seal, and half of the seal is separated. The quality of the sealing of such packaging bags or plastic cups is still unqualified because the contents are easily leaked out by squeezing during storage and transportation.

2.Thermometer display malfunction

It is understood that this failure is also fatal for the fully automatic sealing machine. Once the thermometer fails and cannot control the temperature, the heat sealing temperature will not be constant. The sealing part of the automatic cup sealing machine often appears burnt or not tightly sealed. In this regard, it is recommended that the user check or replace the thermometer, readjust the heat sealing pressure, and replace the heat sealing material.

3.Poor contact of the sealing machine

Because of the unstable operation of the sealing machine, it is necessary to check whether the shaft connection of the motor and the connection of the gearbox are falling off or loose. If these phenomena occur when checking the wear of the carbon brushes of the engines, they need to be tightened and replaced.

In addition to the need to understand and master these three common faults and corresponding solutions, users also need to pay attention to maintenance and maintenance during the shutdown of the equipment so that the equipment can maintain a longer life and ensure the stable operation of production.
